Product Overview
RPF-05 Fully Automatic Top & Bottom Belts Driven Sealer
- Fully automatic adjustment on height and width for various size cartons
- Top & bottom belt driven
This RPF-05 automatic high-speed case sealer is designed to efficiently seal heavy carton boxes due to its design of top and bottom drive belt, it can seal 300 to 750 cases per hour. This automatic case sealing machine is unique in that it can automatically adjust for width and height to seal cases of various sizes. Also adjustable is the machine’s top taping head, which can precisely and stably seal cases. That’s why this automatic high-speed case sealer is widely used in food and beverage, pharmaceutical, electronics, retailing, logistics and other numerous industries requiring high efficiency box taping equipment.
Technical Specifications
Machine Specification
| Carton Size | (L)200mm x (W)200-500mm x (H)180-500mm |
| Table Height | 580-780 mm |
| Working Speed | 300-750 cartons/hr |
| Machine Size | (L)1170mm x (W)880mm x (H)1150mm |
| Power | 110V/220V Single Phase, 50-60Hz |
| Pneumatic | 5 kg/cm2 |
| Tape Width | 48mm, 75mm |
| Machine Weight | 180 kg |
