Product Overview
Features:
1. Adopt direct feed-in type conveyor, no limit of package length. Machine can be incorporated with a line or operated individually.
2. Digital temperature controller assures accuracy sealing temperature.
3. Sensor-controlled production process.
4. The heated, constat-temperature sealing system ensure neat and film sealing.
APW-6030D / APW-8040D / APW-10040D These machines are suitable for packaging of long product; a bundle of drinks, beers, mineral water, easy-open Cans, glass bottles with paper-tray or cardboard box; or any single product.
And coupled with the APT-PE Shrink Tunnel to form a completed packaging line.
Technical Specifications
Machine Specification APW-10040D
| Max. Sealing Width | 1000 mm |
| Max. Pack Height | 400 mm |
| Power Supply | 380V / 3ph / 2500W |
| Max. Packing Speed | 18 ppm |
| Product Feeding | Direct Feed-in Fully Automatic |
| Machine Size (LxWxH) | 1936mm x 1470mm x 2137mm |
| Packed Machine Size (LxWxH) | 2060mm x 1600mm x 2120mm |
| Compressed Air Preasure & Volume | 6 Bar, 80NL/min |
| Machine Weight (Netto / Gross) | 750 / 950 kg |
Machine Specification APW-12540D
| Max. Sealing Width | 1250 mm |
| Max. Pack Height | 400 mm |
| Power Supply | 380V / 3ph / 3000W |
| Max. Packing Speed | 16 ppm |
| Product Feeding | Direct Feed-in Fully Automatic |
| Machine Size (LxWxH) | 1936mm x 1709mm x 2137mm |
| Packed Machine Size (LxWxH) | 2060mm x 1850mm x 2120mm |
| Compressed Air Preasure & Volume | 6 Bar, 80NL/min |
| Machine Weight (Netto / Gross) | 950 / 1250 kg |
Machine Specification APW-6040D
| Max. Sealing Width | 600 mm |
| Max. Pack Height | 350 mm |
| Power Supply | 380V / 3ph / 2000W |
| Max. Packing Speed | 20 ppm |
| Product Feeding | Direct Feed-in Fully Automatic |
| Machine Size (LxWxH) | 1339mm x 1070mm x 2137mm |
| Packed Machine Size (LxWxH) | 1440mm x 1200mm x 2120mm |
| Compressed Air Preasure & Volume | 6 Bar, 60NL/min |
| Machine Weight (Netto / Gross) | 460 / 630 kg |
Machine Specification APW-8040D
| Max. Sealing Width | 800 mm |
| Max. Pack Height | 400 mm |
| Power Supply | 380V / 3ph / 1500W |
| Max. Packing Speed | 20 ppm |
| Product Feeding | Direct Feed-in Fully Automatic |
| Machine Size (LxWxH) | 1339mm x 1270mm x 2137mm |
| Packed Machine Size (LxWxH) | 1440mm x 1400mm x 2120mm |
| Compressed Air Preasure & Volume | 6 Bar, 80NL/min |
| Machine Weight (Netto / Gross) | 530 / 680 kg |
