Product Overview
Features:
1. High speed box motion movement. Higher speed up to 100 packs per minute.
2. Four servo motors control system, products can run on conveyor continuously no stop.
3. PLC and touch screen control, with program memory, can call all production parameter easily.
4. Product changeovers can be easily realized by hand wheel adjustments, no elements need to be replaced.
5. Smaller packing size, less packing film wasting, save materials. Save shrinking time and save energy.
6. With automatic waste strip rewinding device.
Technical Specifications
Machine Specification APSS-5015BM
| Power Supply | 220V / 1ph / 4000W |
| Compressed Air Preasure & Volume | 6 Bar, 10L/min |
| Sealing Bar Width | 500 mm |
| Max. Pack Height | 150 mm |
| Sealing Jaw Driven By | 3 Servo Box Motion |
| Max. Conveyor Speed | 35 m/min |
| Max. Packing Speed | 100 ppm |
| Central Seal Function | Yes |
| Machine Size (LxWxH) | 2740mm x 1623mm x 1700mm |
Machine Specification APSS-7530BM
| Power Supply | 220V / 1ph / 5500W |
| Compressed Air Preasure & Volume | 6 Bar, 10L/min |
| Sealing Bar Width | 750 mm |
| Max. Pack Height | 300 mm |
| Sealing Jaw Driven By | 3 Servo Box Motion |
| Max. Conveyor Speed | 35 m/min |
| Max. Packing Speed | 80 ppm |
| Central Seal Function | Yes |
| Machine Size (LxWxH) | 2740mm x 2023mm x 1700mm |
