Product Overview
Features :
1. AC drive motor with frequency inverter for stepless speed regulation.
2. PID automatic counting control for heating temperature.
3. Feeding, counting, rolling film, sealing, shrinking and cooling in a whole system.
4. Multi-format function is available on request.
5. Option: Teflon net conveyor to make the transportation more stable.
6. For PE, PVC, and Shrinking film.
7. Could be equipped with lane switch device and counting system to pack products without tray. (Customer-made based on product)
Technical Specifications
Machine Specification APW-10040AC / 10040AH
| Max. Sealing Width | 1000 mm |
| Max. Pack Height | 350 mm |
| Power Supply | 380V / 3ph / 3100W |
| Max. Packing Speed | 12 ppm |
| Product Feeding | 90 degree conveyor automatic feeding |
| Machine Size (LxWxH) | 2866mm x 1256mm x 2080mm |
| Packed Machine Size (LxWxH) | 3010mm x 1410mm x 2200mm |
| Compressed Air Preasure & Volume | 6 Bar, 80NL/min |
| Machine Weight (Netto / Gross) | 580 kg / 900 kg |
Machine Specification APW-6030AC / 6030AH
| Max. Sealing Width | 600 mm |
| Max. Pack Height | 300 mm |
| Power Supply | 380V / 3ph / 2000W |
| Max. Packing Speed | 12 ppm |
| Product Feeding | 90 degree conveyor automatic feeding |
| Machine Size (LxWxH) | 2666mm x 1256mm x 2000mm |
| Packed Machine Size (LxWxH) | 2810mm x 1410mm x 2120mm |
| Compressed Air Preasure & Volume | 6 Bar, 60NL/min |
| Machine Weight (Netto / Gross) | 440 kg / 720 kg |
Machine Specification APW-8040AC / 8040AH
| Max. Sealing Width | 800 mm |
| Max. Pack Height | 350 mm |
| Power Supply | 380V / 3ph / 2500W |
| Max. Packing Speed | 12 ppm |
| Product Feeding | 90 degree conveyor automatic feeding |
| Machine Size (LxWxH) | 2666mm x 1256mm x 2080mm |
| Packed Machine Size (LxWxH) | 2810mm x 1410mm x 2200mm |
| Compressed Air Preasure & Volume | 6 Bar, 80NL/min |
| Machine Weight (Netto / Gross) | 500 kg / 790 kg |
