Product Overview
Features:
1. SWING-600 can be set in three different position: inclined 90o, vertical and horizontal based on the product to be wrapped.
2. This machine is equipped with stainless steel frame (AISI 304).
3. The entering of the machine can be on the left.
4. All parts are cantilevered design for easy maintenance and cleaning.
5. Safety guards as required by local law. Safety standard as CEE directives.
6. Possibility to have machines for polyethylene film, for shrink film, etc.
7. On all machines is possible to install: Photocell for printed film, printer for date, line shaft for automatic feeders, etc.
Technical Specifications
Machine Specification
| Wrapping Speed | 20-30 Bags/ Min. |
| Film Reel Width | 600 mm |
| Max. package height | *140 mm |
| Maximum package length | 1000 mm |
| Minimum package length | *50 mm |
| Package width | *50-280 mm |
| External film reel diameter | 300 mm |
| Electrical supply requirements | 230 V 50Hz 1 phase |
| Power supply | 2 Kw |
| Machine weight | 300 kg |
