Product Overview
JN-85PS
Semi Automatic Pallet Strapping Machine
> PP strap (standard), PET strap (optional)
> Customize arch length, L1000MM (standard)
> Inside tension adjuster
> Strap length by self-control
> PLC control (standard)
Features :
- Semi-automatic pallet strapping machine for various requirements when packaging cargo on pallets.
- Moveable design of this model provides convenient operation especially for delicate working place with manual life where cranes cannot reach.
- PP strap dispenser core inner dia: φ200MM (Standard).
- PET strap dispenser core inner dia: φ406MM (Optional).
- The arch size is L1000MM(Standard). Available arch length changed. (Optional)
Technical Specifications
Machine Specification
| Strap Guide Length | 1000mm |
| Dimension | 870mm L x 540mm W x 1380mm H |
| Min. Packaging Height | 550mm |
| Strap width | 12~15mm |
| Sealing method | Heat Sealing |
| Voltage | 110/220V 50/60HZ 1PH. |
| Net Weight | 216Kgs |
