Product Overview
Fully Automatic Stretch Wrapper TP-1650F
Complete with pre-stretch system of 250% (100mm to 250mm)
A fully automatic stretch wrapper machine is an industrial packaging device designed to wrap palletized products with stretch film
automatically. These machines are often used in logistics, warehouses, and production facilities to secure goods on pallets for safe transportation and storage.
With pre-stretch system (250%), The machine stretches the film to 2.5 times its original length before it wraps around the load. This process
allows for optimal film usage, reducing material costs by using less film to cover the same surface area. It also increases load stability by applying tension during wrapping, ensuring that the goods are tightly secured.
Details
- Turntable frequency conversion speed adjustable 0 ~ 12rpm
- PLC programmable control
- The number of top and bottom winding layer can be set separately as required
- Slow start and slow stop for smooth operation.
Technical Specifications
Machine Specification
| Max. Packing Height | 2100mm |
| Turntable Size | Ø1650mm |
| Winding Area | 1000mm x 1000mm |
| Turntable load | 2000Kg |
| Stretch film width | 500mm |
| Machine height | 2400mm |
| Power Source | 220V, 1.5Kw, 50Hz, 1Ph |
